Specifications:
Applicable raw materials: hdpe/ldpe/lldpe
The maximum diameter of the film: 1, 200mm (with the thickness of the film)
The thickness of the film is 0.0.008-0.14mm (depending on the raw material and film width of the production)
Maximum production: ldpe-100kg/h (which is determined by the size of the film and the material used)
Standard configuration
1. extruder
1.1 screw: the diameter of the screw is 65mmmm. The length diameter is :30:1; Material: 38crmoala double bond
1.2 screw speed: : 10-100r/min
Cylinder: cylinder heating: ceramic heating ring cylinder cooling: 3 zone wind and cold, cooling fan: 180w
1.4 temperature control mode: automatic temperature control 3 area ， solid state relay
1.5 reducer: 225 hard tooth reducer
1 extruded the main machine for: 37kw variable frequency motor
2 .The changer
2.1 manual changing device
2.2 converter heating: ceramic heating coil
2.3 Temperature control mode: automatic temperature control 1 area
3. die head
3.1 Basic structure type: single layer screw head structure
3.2 Model 3.2 mould steel
3.3 Specification: ldpe-250mm
3.4 module heating: mica heating ring
3.5 temperature control mode: automatic control temperature 2 zone
4. Air ring
4.1 structure type: single vent cold wind ring
4.2 materials: cast aluminum alloy
4.3 Fan power: 5.5kw
5.Current stabilizer
5.1 structure type: aluminum guide roll
FAQ:
Q:Are you factory or trading company?
A: We are factory and manufacture.
Q: Where is your factory located? How can I visit your factory?
A: We are located in wenzhou, you can fly to wenzhou airport. We can pick you up from the airport to your hotel.
Q:How to place my order?
A: Just contact our Trader Manager, E-mail, WhatsApp，Skype or telephone to confirm the product, make the deposit then we will start to manufacture.
Q:Can you offer some video or pictures of the Q packing machine?
A:Yes, of course. Besides, we can help you to have your products packaging if you are available to send us some of your product and then record a video for your reference.
Q:When can I get my machine after I paid?
A:The delivery time is based on the exact machine you confirmed.
Q:Can you design the machine according to our requirements?
A:Yes. We not only can customize the machine according to your technical drawing, but also can make new machine according to your requirements.
Q:Can you offer overseas technical support?
A:Yes. We can send engineer to your company to set the machine and train your
worker if needed.
